034 Motorsport - (MQB) (AWD) Adjustable Rear Sway Bar - Audi 8V/8S & Volkswagen MK7

£399.78
(No reviews yet) Write a Review
Condition:
New
SKU:
034-402-1015
CATEGORY:
ARB'S + LINKS
Adding to cart… The item has been added

034 Motorsport UK - (MQB) (AWD) Adjustable Rear Sway Bar - Audi 8V/8S & Volkswagen MK7.

* Fits all 8V RS3 sedan, hatchback, pre-facelift and post facelift, also fits MQB EVO vehicles.

* please note all 034 motorsport rear sway bars are made from solid steel. Do not choose your sway bar on thickness alone. This one is 23.8 mm

034 Motorsport is proud to offer the ultimate rear sway bar upgrade for AWD MQB chassis vehicles. The 034Motorsport Adjustable Solid Rear Sway Bar is made from a single piece of high-quality, 0.938 inch thick spring steel for maximum rigidity, and is designed to combat understeer while reducing body roll under hard cornering.

This product was tested thoroughly on the street and track on 034Motorsport's 2018 Audi RS3 and 2018 Audi TTRS Development Vehicles, and multiple enthusiast-owned Audi MQB vehicles before release. The 034Motorsport Adjustable Solid Rear Sway Bar substantially reduces understeer and body roll on 8V Audi RS3 and 8S Audi TTRS vehicles without compromising comfort on the street.

In addition, the 034Motorsport MQB Rear Sway Bar is engineered to be used effectively with the stock front sway bar. No upgrade in the front is required. With the stock front sway bar and upgraded 034Motorsport Solid Rear Sway Bar, body roll is virtually eliminated while turn in and off throttle oversteer are greatly improved.

The RS3/TTRS Spec Rear Sway Bar can also be fit onto the MK7/8 Volkswagen Golf R and 8V/8Y Audi A3/S3. The RS3/TTRS Sway Bar will provide increased body roll reduction and improve rigidity even further!

FEATURES:

  • Manufactured from high-quality, solid, 0.938” spring steel
  • Two positions for adjustability based on driver preference
  • Attractive black powdercoat for protection from the elements
  • Beautiful billet CNC brackets with clear anodizing for protection from the elements
  • Integrated Zerk fittings in the CNC brackets for easy greasing maintenance
  • Locating collars to prevent the sway bar from walking side to side

WHAT'S INCLUDED:

  • 034Motorsport 8V Audi RS3 and Audi TTRS Adjustable Solid Rear Sway Bar
  • Polyurethane Sway Bar Bushings
  • Billet Aluminum Sway Bar Brackets with Integrated Zerk Fittings
  • Sway Bar Bracket Installation Hardware Kit

SWAY BAR RATE DATA:

  • 034Motorsport (Soft) - 81% Rate increase vs. factory Audi RS3/TTRS (21.7mm x 3.0mm) hollow rear sway bar
  • 034Motorsport (Stiff) - 102% Rate increase vs. factory Audi RS3/TTRS (21.7mm x 3.0mm) hollow rear sway bar

RECOMMENDED ALIGNMENT:

034Motorsport RS3 track use alignment specs; these specifications are optimal for a track driven car with a very "loose" handling attitude and lively rear end that drives towards oversteer. Caution should be used with these alignment specs as they can cause the car to over-rotate and spin, especially during throttle-lift conditions while turning:

  • Front: (Tires: 265/35-18 Michelin Sport Cup 2)
    • Camber: -3.0 degrees each side (034-601-1013 camber mounts)
    • Caster: 7.1 degrees (not adjustable)
    • Toe: 0.6mm (toe-in) each side
  • Rear: (Tires: 245/40-18 Michelin Sport Cup 2)
    • Camber: -1.5 degrees each side
    • Toe: 0.8mm (toe-in) each side

Our test vehicle is also running 034Motorsport front and rear sway bars, and all 034Motorsport spherical Motorsport line of products.

FITMENT:

Make Model Years Chassis
Audi A3 2013-Present 8V-MQB
Audi S3 2013-Present 8V-MQB
Audi RS3 2015-2017 8V-MQB
Audi RS3 2018-Present 8V.5-MQB
Audi RS3 2022+ 8Y
Audi TT 2015-Present Mk3-MQB
Audi TTS 2015-Present Mk3-MQB
Audi TTRS 2018-Present 8S-MQB
Audi RSQ3 2020-Present F3-MQB
VW Golf R 2013-Present Mk7-MQB
VW Jetta Sportwagen 4Motion 2015-Present Mk7-MQB
VW Passat Alltrack 2013-Present B7
VW Golf SportWagen 2013-2020 Mk7/Mk7.5
VW Golf Alltrack 2013-2020 Mk7/Mk7.5


* Should fit nearly all MQB AWD (haldex vehicles) and will fit MK8R and A3/S3 8Y
