034 Motorsport UK - X-Clear Driveshaft Tunnel Brace (FWD MQB/MQB EVO) Volkswagen MK7/MK8 & Audi 8V/8S
The X-Clear Driveshaft Tunnel Brace is designed to increase clearance for aftermarket exhausts by replacing the shallow-fitting OEM tunnel brace. This allows for a larger diameter exhaust to be installed without causing excessive rattling or vibration.
The X-Clear Driveshaft Tunnel Brace replaces the factory brace with a CNC Machined Billet 6061-T6 Aluminum brace designed to increase exhaust clearance by 8mm over factory.
FEATURES:
- Increased Stiffness Over OE Stamped Steel Part
- CNC Machined from Billet 6061-T6 Aluminum
- Bright Black Anodizing, with Laser Etched 034Motorsport Logo
- Adds 8mm of Additional Clearance to Exhaust Compared to the OE Part, Allowing Larger Diameter (up to ½” diameter larger) Aftermarket Exhaust Installation
- Fast, Easy Installation
- No Added NVH
WHAT’S INCLUDED:
- Billet Tunnel Brace
- Mounting Hardware
OE Part Interchange:
- 5Q0 804 421 B
- 5Q0 802 128
FITMENT:
| Make | Model | Years | Chassis | Engine |
|---|---|---|---|---|
| Audi | A3 FWD Only | 2015-2016 | 8V | 1.8 TFSI |
| Audi | A3 FWD Only | 2015-2016 | 8V | 2.0 TDI |
| Audi | A3 FWD Only | 2015-2020 | 8V/8V.5 | 2.0 TFSI |
| Audi | A3 FWD Only | 2022-Present | 8Y | 2.0 TFSI |
| VW | Golf | 2015-2020 | Mk7/Mk7.5 | 1.8T Gen3 |
| VW | Golf | 2015-2016 | Mk7 | 2.0 TDI |
| VW | Golf SportWagen | 2015-2020 | Mk7/Mk7.5 | 1.8T Gen3 |
| VW | GTI | 2015-2020 | Mk7/7.5 | 2.0T Gen3 |
| VW | GTI | 2021-Present | Mk8 | 2.0T Gen4 |
