034 Motorsport UK - Turbo Inlet Pipe - Volkswagen Golf MK8 R & Audi 8Y S3 - EA888.4 (EVO)
* should fit all high output EA888 gen 4 motors with continental turbo
The 034 Motorsport Turbo Inlet Pipe for the 2.0T MQB-Evo, Volkswagen MK8 Golf R, and Audi 8Y S3, is an essential upgrade to optimize power by eliminating a critical flow restriction in the intake tract. The MQB-Evo 2.0T Turbo Inlet Pipe is manufactured from 70mm thin wall 6061-T6 aluminum for maximum airflow, with a machined 6061-T6 billet aluminum compressor inlet flange that perfectly mates to allow smooth air entry into the compressor housing. Machined 6061-T6 billet aluminum elements are used to retain the original PCV hose fitting and original mounting location.
The MQB-Evo 2.0T Turbo Inlet Pipe is designed to work with OEM-style turbo inlet hoses. The bead-rolled edge retains the inlet hose securely to the inlet pipe. The final touch is a durable black wrinkle-coat finish for long-lasting good looks with a laser etched 034 logo to top it all off!
The 034Motorsport Turbo Inlet Pipe utilizes a CNC-machined billet aluminum adapter ring that is perfectly matched to the factory turbo compressor housing. This unique oval shaped adapter ring is designed to be a smooth air entry between the turbocharger and Turbo Inlet Pipe that utilizes an O-ring to seal the adapter to the inlet. This solution will allow the 034Motorsport Turbo Inlet Pipe adapt to future turbo upgrades with larger turbo inlet adapter ring sizes.
FEATURES:
- CNC Machined, Billet Aluminum Flange
- Compressor Inlet Flange Adapter Machined for Smooth Airflow Into Compressor Housing
- CNC Machined 6061-T6 Aluminum Turbo Inlet Adapter to Match Turbo Inlet for Maximum Airflow
- Additional Adapter Rings Will Be Available In the Future
- Proven Power/Torque, and Airflow Gains
- OE 8Y S3 / Golf R Assembly: 437.38 CFM @ 28 in.H20
- Insuction Bundle: 535.81 CFM @ 28 in.H20
- ~ 22.50% Increase
- Direct Bolt-on Installation
WHAT'S INCLUDED:
- (1x) Turbo Inlet
- All Necessary Hardware
FITMENT:
| Make | Model | Years | Chassis | Engine |
|---|---|---|---|---|
| Audi | S3 | 2022-Present | 8Y | 2.0 TFSI |
| VW | Arteon | 2022-2024 | I.5 | 2.0T Gen4 |
| VW | Golf R | 2021-Present | Mk8 | 2.0T Gen4 |
